Controller K8BP.E

Location: BB Canopy 01

Gallery

Setup Photos image 1 for controller K8BP.E

Site Map image 1 for controller K8BP.E

BB Canopy 01

5 data pigtails

Controller Photos image 1 for controller K8BP.E

Controller Photos image 2 for controller K8BP.E

Props

Controller	Controller Port	Mode	Receiver	Controller Output	Dumb Receiver	Smart Receiver	Box Type	Network Path	Max Px/Port	Pixels on Port	Pixels Used	Pixels Left	Power Supply	Voltage	Max Wattage	Watts/ Node	Brightness Percentage	Watts/ Port	Watts Drawn	Control Box Name	Cable Length	Prop 1 Name	Px Count	Cable Length (2)	Prop 2 Name	Px Count (2)
K8PB.E	1	1	1E	0				SELF	800	1	1	799	1E	12	750	10	75	7.5	130.8	BB Canopy 01	19	10w Flood 032	1
K8PB.E	2	2	2E	0					800	168	168	632	1E	12	750	0.6	50	50.4		BB Canopy 01	19.5	MiniMatrix 26.2	84	0	MiniMatrix 26.1	84
K8PB.E	3	3	3E	0					800	1	1	799	1E	12	750	10	75	7.5		BB Canopy 01	2.5	10w Flood 033	1
K8PB.E	4	4	4E	0					800	168	168	632	1E	12	750	0.6	50	50.4		BB Canopy 01	2	MiniMatrix 27.2	84	0	MiniMatrix 27.1	84
K8PB.E	5	5	5E	0					800	50	50	750	1E	12	750	0.6	50	15		BB Canopy 01	17.5	Fence 11	50
K8PB.E	6	6	6E	0					800	0	0	800	1E	12	750	0.6	50	0		BB Canopy 01
K8PB.E	7	7	7E	0					800	0	0	800	1E	12	750	0.6	50	0		BB Canopy 01
K8PB.E	8	8	8E	0					800	0	0	800	1E	12	750	0.6	50	0		BB Canopy 01

Controllers

1 box available

Show details

5 data pigtails

Controller Role

K8PB.E

Pigtails

5 Data

Build Checklist

Control Box Created
Props Placed
Control Box Mounted
Props Wired (Data/Power)
120V Power Connected
Data Link (Ethernet/RS485)
Tested
Zip-tied / Cables Cleaned
