Controller K3A

Location: MiniMatrix 03

Gallery

Cable Schedule

Control box MiniMatrix 03

This box is not flagged as color coded, yet 4 of its 4 cables carry a code. The tape on the pigtail is the truth — check it against this list before trusting it.

Cable	What is on it, in order
Yellow	7′ 10w Flood 037 1 px 6′ 10w Flood 036 1 px
Blue	24.5′ MiniMatrix 15 168 px
Green	1′ MiniMatrix 16 84 px
Brown	17.5′ MiniMatrix 17 84 px

Controllers

1 box available

Show details

4 data pigtails

Controller Role

K40D.K

Pigtails

4 Data

Build Checklist

Control Box Created
Props Placed
Control Box Mounted
Props Wired (Data/Power)
120V Power Connected
Data Link (Ethernet/RS485)
Tested
Zip-tied / Cables Cleaned
